The Shimano Deore 10-speed chainring for the FC-M6000-2 crankset

This Shimano chainring is compatible with the Deore FC-M6000 2x10-speed cranks. Three combinations can be formed: 24-34, 26-36 and 28-38. The chainrings are also suitable for the FC-M6000 with a chainline 3 mm further out.

Specifications:

Application: Trail, All Mountain, Cross Country
Mount: 96/64 mm pitch circle diameter, 4-arm asymmetrical
Teeth: 24 t, 26 t, 28 t, 34 t, 36 t, 38 t
Gearing: 2x10-speed

Technical Information:

Combinations: 24 - 34 t, 26 - 36 t, 28 - 38 t
Material: steel (24 t to 28 t), aluminium/fibreglass composite (34 t to 38 t)

Compatibility:

- Deore FC-M6000-2
- Deore FC-M6000-B2

Features:

- large chainring anodised, small chainring painted

Models:


28 tooth:
- Type: BG
- Bolt Circle Diameter: 64 mm
- Manufacturer Part Number: Y-1WD28000



38 tooth:
- Type: BG
- Bolt Circle Diameter: 96 mm
- Manufacturer Part Number: Y-1WD98030

Charakteristikos

Pavaros
10
Disciplina
MTB
B.C.D (mm)
96
Montavimo taškai
4
Y1WD98030
1 Prekės

Charakteristikos

Pavaros
10
Disciplina
MTB
B.C.D (mm)
96
Montavimo taškai
4
