The Shimano XT 11-speed chainring for the FC-M8000 crankset

This Shimano chainring is an original spare part for the XT FC-M8000 11-speed cranks, also for the version with 3 mm outer chainline. It has four asymmetrically arranged arms and a pitch circle diameter of 96 or 64 mm. The chainrings can be used for the 2x combinations 28-38.

Specifications:

Application: Cross Country, All Mountain
Mount: 96/64 mm pitch circle diameter, 4-arm asymmetrical
Teeth: 28 t, 38 t
Gearing: 2x11-speed

Technical Information:

Combinations: 28 - 38 t
Material: aluminium (24 t to 28 t), aluminium/carbon (CFRP, 34 t to 38 t)

Compatibility:

- XT FC-M8000
- XT FC-M8000-B
- 24/26 t is also compatible with FC-MT700(-B2)

Features:

- large chainring painted, small chainring plated

Models:


28 tooth:
- Type: BD
- Bolt Circle Diameter: 64 mm
- Manufacturer Part Number: Y-1RL28000


38 tooth:
- Type: BD
- Bolt Circle Diameter: 96 mm
- Manufacturer Part Number: Y-1RL98090



Charakteristikos

Pavaros
11
Disciplina
MTB
B.C.D (mm)
96
Montavimo taškai
4
Y1RL98090

Charakteristikos

Pavaros
11
Disciplina
MTB
B.C.D (mm)
96
Montavimo taškai
4
