The Shimano Tiagra 10-speed chainring for the FC-4700 crankset
This Shimano 10-speed chainring is an original spare part for the Tiagra FC-4700 cranks and can be used for the 2x combinations 34-50 and 36-52 (bolt circle 110 mm). The small chainrings are made of aluminium, the large ones of an aluminium-plastic composite.
Specifications:
Application: Road, City
Mount: 110 mm pitch circle, 4-arm asymmetrical
Teeth: 34 t, 36 t, 50 t, 52 t
Gearing: 2x10-speed
Technical Information:
Combinations: 34-50 t, 36-52 t
Material: aluminium (34 + 36 t), aluminium/composite (GFRP 50 t + 52 t)
Compatibility:
- Tiagra FC-4700
Features:
- anodised
Models:
34 tooth:
- Type: MK
- Manufacturer Part Number: Y-1RC34000
36 tooth:
- Type: ML
- Manufacturer Part Number: Y-1RC36000
50 tooth:
- Type: MK
- Manufacturer Part Number: Y-1RC98050
52 tooth:
- Type: ML
- Manufacturer Part Number: Y-1RC98060
Note to Type Designation:
The type designations (with one or two letters) indicate that the chainrings can be combined with each other. Since the large rings have specially shaped teeth and shifting aids that make it easier for the chain to climb, full shifting performance is only guaranteed with matching small rings - and vice versa. A chainring of type XY should therefore only be ridden with a chainring of type XY. The same applies to all other types.
Charakteristikos
- Pavaros
- 10
- Disciplina
- Road
- B.C.D (mm)
- 110
- Montavimo taškai
- 4
